Accessories
Architectural and Environmental Accessories
A-WALL modular offices and in-plant buildings can be equipped for virtually any application. They arrive on-site completely pre-engineered and include doors, windows, air conditioners – everything needed to complete your project.
The accessories that follow are those most commonly needed. Custom options and sizes not shown are also readily available.
Doors
Man Doors – 3′ x 6′-8″ x 1¾” solid core birch doors or insulated painted steel doors.
Double Doors – 6′ x 6′-8″ x 1¾” solid core birch doors or insulated painted steel doors.
Note: Doors are provided complete with aluminum frame, keyed lever lockset, hinges and stop.
Door Glass – 22″ x 36″ with tempered, acrylic, laminated, insulated or wire glass, factory glazed.
Door Louvers – 24″ x 12″ vision-proof, factory installed.
Door Closers – high quality, commercial grade or as specified.
Panic Hardware – key in knob or crash bar, commercial grade or as specified.
Impact Doors – various styles and sizes with painted, structural steel frames.
Roll-Up Doors – metal or fabric with painted, structural steel frames.
Removable Access Panels – used in place of doors for infrequent access to equipment in the building.
Windows
Desk Height Windows – 39″ x 44″ x 3/16″, or 15″ x 44″ x 3/16″, 36″ above floor.
Surveillance Windows – 39″ x 60″ x 3/16″, 18″ above floor.
Note: Windows are factory installed in wall panels with tempered, acrylic, laminated, insulated or wire glass.
Sliding Windows – 36″ x 38″ sliding tempered glass, field assembled in factory framed opening.
Window Tinting – factory applied film in assorted shades and degrees of UV filtration.
Heating, Ventilation and Air Conditioning
Thru-the-Wall Units – cooling only or with electric heat/heat pumps.
Air Conditioner Cut-Outs – factory framed openings for thru-the-wall units.
Positive Room Pressure Systems – isolates the room from airborne dust and particulate.
Negative Room Pressure Systems – contains airborne dust and particulate within the room.
HEPA Filter/Blower Modules – self-contained units for cleanrooms and white rooms.
Electric Heaters – fan forced wall mounted or baseboard units, each with thermostat control.
Exhaust Fans – ceiling mounted with prefabricated duct and factory-wired wall switch.
Sound and Temperature Control
Ceiling Insulation – 2’x4’x6″ fiberglass batts install above ceiling tiles for acoustical and thermal insulation.
Basetrack Gasket Tape – self-adhesive foam tape seals void between basetrack and floor.
Steel Roof Deck Closures – foam inserts for sealing corrugated ends of deck at sidewalls.
Door Seals – closed cell, neoprene gasket seals door at door frame.
Mechanical & Rubber Doors Sweeps – seals gap at bottom of doors.
Optional Ceiling Components
NRC = 70 Ceiling Tiles – 2’x4′ mineral board, acoustic tiles with 25% more sound absorption than standard tiles.
Vinyl Clad Gypsum Ceiling Tiles – 2’x4’x1/2″ gypsum tiles with washable white, vinyl surface.
1.5″ Aluminum Ceiling Grid – supports gypsum tiles and the added weight of HEPA filters in modular cleanrooms.
Ceiling Grid Gasket Tape – closed cell, neoprene gasket tape provides seal between gypsum tile and ceiling grid.
Pre-Wired Wall Panels
Only with A-WALL can your switches, outlets and data boxes be installed wherever you’d like.
