A-WALL Panels

Standard Panels

A-WALL panels are 2-5/8″ thick, 4′ wide and either 8′ or 9′ high. They can be cut to specific widths or stacked to meet the dimensional needs of your project. The standard panel is constructed of Type X, Firecode® gypsum board with a specially formulated core that’s a superior fire barrier compared to regular drywall. The gypsum panel surfaces are “decoupled” by insulating ribs which significantly reduce sound transmission from one side of the panel to the other. These ribs also create three, independent wiring cavities which are sized to accept standard electrical boxes and allow for unlimited wiring flexibility. You can request single or ganged switches and outlets, as well as phone and data boxes practically anywhere you need them. And later, you can install additional devices in the panels when needed using off the shelf electrical components.




Poly-Core Panels

An optional Poly-Core is available for buildings being located in severe environments such as refrigerated warehouses or next to production furnaces. Poly-Core increases the insulating value of the panel to R-9.



Panel Finishes

A-WALL panels are factory finished with your choice of three durable, washable surfaces.

  • Vinyl Clad Gypsum – 6 mil., Class A fire rated, stipple textured vinyl. Bone and white are standard.
  • FRP Clad Gypsum – Pebble textured, Class C fire rated, Fiberglass Reinforced Plastic. Khaki and white are standard. Smooth and Class A also available.
  • Steel Clad Gypsum – Smooth, 24 gauge, galvanized, painted steel. Almond and white.

Unfinished gypsum panels are also available. They can be painted on-site to match your corporate color scheme. Window frames, door frames and accent trim are factory finished dark bronze to hide dirt and hand prints.


EPS Core Panels

A-WALL EPS (expanded polystyrene) Core Panels can be used outdoors or in wet environments. Typical applications are food processing plant offices and equipment wash booths, where water will be splashed or sprayed on the walls.

EPS core panels provide an insulating value of R-12. Wiring is surface mounted in conduit or Wiremold to maintain the wall’s thermal properties. They are available surfaced with fiberglass reinforced plastic (FRP), steel, or embossed aluminum.

Exclusive Features and Accessories

Click on any of the tabs below to learn more about features and accessories for your A-WALL modular office or inplant building.

A-WALL panels are constructed like a permanent, stud and drywall wall. However, the standard panels feature Type X, Firecode® gypsum board with a specially formulated core that's a superior fire barrier compared to regular drywall. The gypsum board panel surfaces are "decoupled" by insulating ribs which significantly reduce sound transmission from one side of the panel to the other. These ribs also create three, independent wiring cavities which are sized to accept standard electrical boxes and allow unlimited wiring flexibility. You can request single or ganged switches and outlets, as well as phone and data boxes wherever you need them. And later, you can install additional devices in the panels when needed using off the shelf electrical components.

Learn More

Both standard and poly-core A-WALL panels are shipped with UL Listed switch and receptacle assemblies factory installed and wired in the panels. You specify the electrical devices you require and designate their locations. The standard electrical package includes a main breaker panel, 2’ x 4’ recessed, fluorescent light fixtures, switches, receptacles and device boxes with pull lines for your communication and data wiring.

Learn More

A-WALL buildings can be equipped for virtually any application with a range of optional accessories.

  • Doors
  • Windows
  • Heating, Ventilation and Air Conditioning
  • Sound and Temperature Control
  • Ceiling Systems

Learn More

Did You Know?

A-WALL modular offices are shipped with U.L. listed switch and outlet assemblies factory installed in the wall panels.

Factory wired panels reduce your installation time and labor cost.
